Solar PV Panel Recycling Plant

Scope of feeding materials

Most materials of waste soalr PV modules can be recycled, including 65%-7% glass, 10%plastic(encapsulant and backsheet), 3%-5%silicon and 1% copper and less than 0.1% of silver, tin and lead, although the content is small, but the recycling value is large. The recovery rate can reach to more than 98%.

Final Product

The Solar Panel Recycling Machine primarily employs a combination of physical, chemical, and thermal processing techniques to handle various types of photovoltaic panels, achieving the separation and recovery of aluminum frames, glass, metals, silicon powder and plastics.

Aluminum frame removal rate ≥ 99%, recycling purity ≥ 98%.

Glass removal rate 85-95%, recycling purity ≥ 90%.

Metal particle (copper) recovery rate ≥ 95%, recycling purity ≥ 95%.

Plastic powder recovery rate ≥ 95%, recycling purity ≥ 90%.

Silicon recovery rate 95%, appears in the form of a mixture of plastic powder, glass powder, etc., with a silicon content of about 45%.

Product Advantages

1.High separation rate: frame remove rate≥99%, glass remove rate 85-95%, metal separation rate≥95%;

2.Reasonable layout, stable performance and low noise;

3.PLC control system can improve work efficiency and save labor cost.

4.The whole system adopts closed operation, negative pressure transfer. Dust can be collected effectively. There is no dust leakage. System is safety and environmental protection.

The Solar Panel Dismantler quickly separates the aluminium frames of solar panels, preserving the integrity of the aluminium material for recycling and reducing damage to glass and silicon materials. It improves dismantling efficiency, replaces traditional manual operations, and reduces labour costs and safety risks. It also helps to promote the sustainable development of the photovoltaic industry.

TECHNICAL PARAMETERS
